RS 3DII infrared Wheel Alignment Equipment

Category: Garage Equipment
Sub Category: Wheel Aligners

Main Features

  • Comes with Windows 7 computer system with HP computer and mobile cabinet.
  • Easy to operate with guiding menu, to read alignment database within 3 minutes.
  • No electric element & battery
  • Transmission cable, Bluetooth & infrared ray on the target plates to reduce fault.
  • Calibration done at the factory.
  • Wide range of sight with high performance digital camera.
  • Different colors of led to show different step in operation.
  • User can operate different steps according to the color changing on screen.
  • Set with Volkswagen dedicated application, can measure toe-arc for A6,B5.
  • 26 different languages including English.
  • Suitable for vehicle with super-low chassis.
  • Integrated cabinet.
  • 25000 vehicle database, online updating.
  • CE Certification.

Standard Accessories Included

  • Camera beam x 1
  • Computer x 1
  • Printer x 1
  • Turnplate x 2
  • Brake lock x 1
  • Steel wheel lock x 1
  • Target plate x 4
  • Wedge x 1
  • Hanger for clamp x 4


Technical Data

Item

Measurement Accuracy

Measurement Range

Total Measurement Range

Camber

±0.01°

±8°

±8°

Caster

±0.05°

±19°

±19°

Front wheel KPI

±0.02°

±19°

±19°

Total Toe

±0.01°

±2°

±8°

Rear wheel thrust angle

±0.01°

±2°

±4°

Toe-out on turn

±0.08°

±2°

±40°

Axle offset of Rear wheel

±0.02°

±2°

±4°

Wheel tread difference

±0.03°

±2°

±8°

Front setback

±0.02°

±2°

±4°

Rear setback

±0.02°

±2°

±4°

Wheel tread

±0.64cm(±0.25cm)

<265cm(<105in)

<265cm(<105in)

Wheelbase

±0.64cm(±0.25cm)

<533cm(<210in)

<533cm(<210in)
